Adder ADR-ALIF2124T-US INFINITY Dual Head Digital Video-Audio & USB2.0 over 1GbE IP Network KVM Extender

The ADDERLink INFINITY 2124 is a high performance IP KVM (Keyboard, Video and Mouse) extender that forms part of the ALIF matrix solution. This enables the relocation of critical computing hardware into a secure and temperature controlled environment away from the user work station; whilst maintaining a pixel-perfect desktop experience.

• HDMI connectivity
• 2x SFP ports for maximum flexibility. Can be used with either CATx or fiber modules, allowing distances of up to 20km
• Video resolutions up to 1x 2560x1600 @60Hz or 2x 1920x1200 @60Hz
• USB mass storage devices supported plus keyboard, mouse, tablet and touch
• Plug and play
• Redundant network operation

• Computer Connections; 1x USB B 2.0 (True Emulation, High Speed); 1x USB A 2.0 (True Emulation) (Auxiliary connection); 2x HDMI;
• Audio; Audio in Port - 1 x USB; Audio Type - Analog/Digital; Channels - 2; Audio Direction - Bi-directional; Audio Additional Information - Analog audio and audio via video connector is uni-directional; Size (bit) - 16; Speed (kHz) - 48;

• Link Ports: 2x SFP
• Serial Comms: RS232 or other serial
• Bandwidth: 1GbE
• Power Type: 1 x 12V 3-pin Kycon
• Maximum Power (Watts): 18
• Typical Power (Watts): 7
• Dimension (HxWxD): 1.5 x 5.3 x 5.9" (39 x 136 x 150mm)
• Weight: 1 lbs
